GW212
12" Poly Laminated Paper Cone Woofer
1.5" Aluminum Voice Coil
Pressed Steel Frame
Foam Edge
Vented Pole Piece
20 Ounce Magnet
Bumper Plate
34-2000 Hz
120 Watts RMS

Speaker Physical Characteristics

Speaker Frame Outer Diameter = 12" (305mm) Magnet Diameter = 4¾" (121mm) Cut-out Diameter = 11" (280mm) Mounting Depth = 4¾" (121mm) Diagonal Mounting Hole Dimension (center to center) = 11 5/8" (295mm)

GW212/4 T/S Parameters Symbol Value Z 4 ohms Re 3.6 Ohms Fs 35.8 Hz Qms 6.072  Qes  1.502 Qts 1.204 Vas 166.6 Ltr Sens 92.3 dB

GW212/8 T/S Parameters Symbol Value Z 8 ohms Re 7.0 Ohms Fs 38.8 Hz Qms 5.271  Qes  1.978 Qts 1.438 Vas 101.6 Ltr Sens 87.2 dB

GW212/4

GW212/8




Pricing Part No. Each Case of 4 GW212/4 $33.90 $23.50 each

Pricing Part No. Each Case of 4 GW212/8 $33.90 $23.50 each
