Shielded Woofers from Chokes Unlimited
Contact Information
GWE1S Shielded Magnet Woofer
With Bucking Magnet and Can
5.25" Poly Treated Paper Cone
16 Ounce Shielded Magnet
1" Flat Wire Voice Coil
Butyl Rubber Surround
Pressed Steel Frame
50 Watts RMS
50 - 8,800 Hz
 85dB 1W/1M
16 ohm
Speaker Physical Characteristics
OD= 5 7/16" (138mm)
Cut-out Diameter = 4 7/16" (112.7mm)
Mounting Depth = 2 3/4" (70mm)
Diagonal Mounting Hole Dimension (center to center) = 5" (127mm)
Speaker Terminals: [+] = .110"  [-] = .187"
Shielded Woofer GWE1S
GWE1S
T/S Parameters
Symbol
Value
Z
16 ohms
Re
11.2 Ohms
Fs
67 Hz
Qms
3.373
Qes
 .443
Qts
0.391
Vas
4.41 Ltr
Sens
85 dB
Pricing
Part No.
Each
Case of 8
GWE1S
$13.98
$8.00 each
