GW1038PA
10" Musical Instrument/P.A. Woofer
Paper Cone
1.5" Aluminum Voice Coil
Pressed Steel Frame
Vented Pole Piece
30 Ounce Magnet
Accordian Edge
Bumper Plate
58-3000 Hz
120 Watts
8 Ohms

Click here to view a customer review.
T/S Parameters
Symbol
Value
Z
8 ohms
Re
7.3 Ohms
Fs
63.3 Hz
Qms
4.188
 Qes
 1.211
Qts
0.939
Vas
47.1 Ltr
Sens
92.2 dB
Speaker Physical Characteristics
Speaker Frame Outer Diameter = 10" (254mm)
Magnet Diameter = 4¾" (121mm)
Cut-out Diameter = 9¼" (235mm)
Mounting Depth = 3 7/8" (98mm)
Diagonal Mounting Hole Dimension (center to center) = 9 5/8" (245mm)
Pricing
Part No.
Each
Case of 6
GW1038PA
$40.06
$33.00 each
