GW1058
10" Musical Instrument/P.A. Woofer
Polymer Laminated Paper Cone
2.5" Aluminum Voice Coil
Pressed Steel Frame
Accordian Surround
Vented Pole Piece
50 Ounce Magnet
Bumper Plate
180 Watts
8 Ohms
T/S Parameters
Symbol
Value
Z
8 ohms
Re
5.281 Ohms
Fs
43.446 Hz
Qms
2.696
 Qes
 0.459
Qts
0.392
Vas
63.678 Ltr
Sens
94.190 dB


Speaker's Physical Characteristics
Speaker Frame Outer Diameter = 10 3/16" (259mm)
Magnet Diameter = 6 1/18" (156mm)
Cut-out Diameter = 9 3/16" (233mm)
Mounting Depth = 4½" (114mm)
Diagonal Mounting Hole Dimension (center to center) = 9¾" (248mm)


Pricing
Part No.
Each
Case of 4
GW1058
$44.89
$39.50 each
