10 Woofer from Chokes Unlimited
Contact Information
GW10PC
10" Poly Mica Cone Woofer
1.5" 4-Layer Aluminum Voice Coil
Cast Frame
Butyl Rubber Edge
Vented Pole Piece
40 Ounce Magnet
Bumper Plate
39-2200 Hz
200 Watts RMS
Speaker Physical Characteristics
Speaker Frame Outer Diameter = 10¼" (260mm)
Magnet Diameter =  5½" (140mm)
Cut-out Diameter = 9 1/8" (232mm)
Mounting Depth = 4 3/8" (11mm)
Diagonal Mounting Hole Dimension (center to center) = 9¾" (248mm)
GW10PC/4
T/S Parameters
Symbol
Value
Z
4 ohms
Re
3.8 Ohms
Fs
43.1 Hz
Qms
4.252
 Qes
 0.446
Qts
0.403
Vas
32.7 Ltr
Sens
92.7 dB
10 Woofer, 10 Subwoofer
GW10PC/8
T/S Parameters
Symbol
Value
Z
8 ohms
Re
7.227 Ohms
Fs
47.9 Hz
Qms
4.849
 Qes
 0.525
Qts
0.474
Vas
31.014 Ltr
Sens
90.4 dB
10 Woofer 4 ohms
GW10PC/4
10 Woofer 8 ohms
   GW10PC/8
Pricing
Part No.
Each
Case of 6
GW10PC/4
$52.38
$47.50 each
Pricing
Part No.
Each
Case of 6
GW10PC/8
$52.38
$47.50 each
