GW1238PA
12" Musical Instrument/P.A. Woofer
Paper Cone
1.5" Aluminum Voice Coil
Pressed Steel Frame
Vented Pole Piece
30 Ounce Magnet
Accordian Edge
Bumper Plate
49-6000 Hz
120 Watts
8 Ohms
T/S Parameters

Symbol
Value
Z
8 ohms
Re
7.1 Ohms
Fs
43.4 Hz
Qms
3.287
 Qes
 0.893
Qts
0.702
Vas
164.1 Ltr
Sens
94.1 dB
Speaker Physical Characteristics
Speaker Frame Outer Diameter = 12" (305mm)
Magnet Diameter = 4¾" (121mm)
Cut-out Diameter = 11" (280mm)
Mounting Depth = 4½" (114mm)
Diagonal Mounting Hole Dimension (center to center) = 11 5/8" (295mm)
Pricing
Part No.
Each
Case of 4
GW1238PA
$43.92
$37.00 each
