GW208
8" Poly Laminated Paper Cone Woofer
1.5" Aluminum Voice Coil
Pressed Steel Frame
Foam Edge
Vented Pole Piece
20 Ounce Magnet
Bumper Plate
45-6000 Hz
100 Watts RMS
Speaker Physical Characteristics
Speaker Frame Outer Diameter = 8" (203mm)
Magnet Diameter = 3 15/16" (99mm)
Cut-out Diameter = 7 1/4" (184mm)
Mounting Depth = 3 1/4" (83mm)
Diagonal Mounting Hole Dimension (center to center) = 7 9/16" (192mm)
GW208/4
T/S Parameters
Symbol
Value
Z
4 ohms
Re
3.7 Ohms
Fs
51.5 Hz
Qms
4.111
 Qes
 0.847
Qts
0.702
Vas
22.8 Ltr
Sens
90.8 dB
GW208/8
T/S Parameters
Symbol
Value
Z
8 ohms
Re
7.3 Ohms
Fs
56.1 Hz
Qms
3.964
 Qes
 1.092
Qts
0.856
Vas
22.8 Ltr
Sens
87.9 dB

GW208/4

GW208/8
Pricing
Part No.
Each
Case of 8
GW208/4
$18.25
$16.50 each
Pricing
Part No.
Each
Case of 8
GW208/8
$18.25
$16.50 each
