GW6PC
6½" Poly Mica Cone Woofer
1.5" 4-Layer Aluminum Voice Coil
Cast Frame
Butyl Rubber Edge
Vented Pole Piece
20 Ounce Magnet
Bumper Plate
46 - 3800Hz
100 Watts RMS
Speaker Physical Characteristics
Speaker Frame Outer Diameter = 6 7/8" (175mm)
Magnet Diameter = 3 15/16" (99mm)
Cut-out Diameter = 5 15/16" (151mm)
Mounting Depth = 3 5/16" (84mm)
Diagonal Mounting Hole Dimension (center to center) = 6 5/16" (160mm)


GW6PC/4
T/S Parameters
Symbol
Value
Z
4 ohms
Re
3.7 Ohms
Fs
44.2 Hz
Qms
5.978
 Qes
0.490
Qts
0.453
Vas
21.3 Ltr
Sens
90.0 dB
GW6PC/8
T/S Parameters
Symbol
Value
Z
8 ohms
Re
7.4 Ohms
Fs
59.3 Hz
Qms
6.306
 Qes
 0.496
Qts
0.460
Vas
7.6 Ltr
Sens
87.2 dB

GW6PC/4

GW6PC/8
Pricing
Part No.
Each
Case of 8
GW6PC/4
$28.94
$24.00 each
Pricing
Part No.
Each
Case of 8
GW6PC/8
$28.94
$24.00 each
